Specifications:
- Direct drive gear system with better efficiency
- Operating Voltage Range: 4.8V~8.4V
- Gear Material: Titanium metal gear
- Weight: ~42g
- Dimension: 41mm (L) x 26.5mm(W) x 20mm(H)
- Stall Torque: 10kg-cm @6V, [email protected], [email protected]
- Operating Speed(with no load): 0.065 sec/60°@6V, 0.055 sec/60°@7.4V, 0.05 sec/60°@8.4V
Improved features based on DCS V3 servo:
- Allow to program the below items through the optional servo program card to maximize the overall servo performance.
(Items: Max Power band, Turn Boost, Dead Band, Response Level, Max Torque, Turn Brake and Center Adjustment). However, the servo program card is optional and is not included with the packing
- Support SHR/SRS/SUR mode
- Hybrid titanium/steel gear for durability to enhance the maximum durability
- New upper plastic casing design for better durability
