Tamiya 84432 - 1/10 TRF102 Black Edition Chassis Kit 田宮遙控模型方程式賽車套件雙星孖星 [84432]

價格:

HKD$1,896.12

牌子:

Tamiya

型號:

84432

GTIN:

4950344844326

售罄

請輸入姓名和電子郵件地址。當貨品重新上架我們將笫一時間通知閣下.

你或可於 R/C Models - On-Road - Formula Cars
類別中嘗試尋找類似的產品

填寫評論

alt="Tamiya 84432 - 1/10 TRF102 Black Edition Chassis Kit" title="Tamiya 84432 - 1/10 TRF102 Black Edition Chassis Kit"

產品說明

This is a \"BLACK EDITION\" of the TRF102 Formula One Chassis kit. All the aluminum parts are anodized in black, whereas the original kit was anodized in the world-famous Tamiya Blue.

The TRF102 is the second-generation high-performance Formula One chassis designed by Tamiya\'s elite designers. This iteration is a revolution! The kit features a number of changes to provide superior performance especially with rubber tire applications and outdoor track use. Both the front and rear of the car have been redesigned to fully utilize the flexibility of the chassis, with the effect of excellent road holding and response.
Key Design Points:

The New T-Bar design provides a progressive roll damping effect superior to that offered by the spring-actuated side links on the TRF101. The roll point ball has been placed in as low a position as possible, in order to maximize damping effect. 2 thicknesses of T-bar (1.5mm and 1.8mm) are included.

The brand-new pitch axle gives vastly improved, independent pitch damping, letting the chassis deal much more smoothly with undulating surfaces.

Servo mount screws are attached closer together on the lower deck. This, in combination with the floating battery mount, allows greater expression of lower deck flexibility, giving the feeling of greater stroke at the front of the car. A new servo stiffener keeps the servo firmly in place.

Slits are cut into the lower deck to further enhance its flexibility.

The roll damper has been moved closer to the lower deck, giving a more compact rear and contributing to the chassis\' low center of gravity.

TRF102 Carbon Lower (2.5mm Thick) & Upper (2.0mm Thick) Decks

TRF102 Aluminum Motor Mount

F104 Low-Friction Suspension Balls

Reinforced Carbon Reinforced Plastic Front Suspension Arms

TRF102 T-Bar Rear Suspension

Adjustable Metal Upright Set

Integrated Diff Plate/Carbon Rear Shaft

TRF102 Aluminum Servo Stay

1.5mm & 1.8mm T-bars

Hi-Torque Servo Saver

TRF Damper

Specifications

Scale : 1/10
Construction type : Assembly kit
Terrain use : On-Road
Drive-train : 2WD RWD
Drive type : Pinion to spur gear
Drive line : Solid axle
Differential type : Ball pressure plate
Suspension : Front kingpin coil spring independent suspension/solid axle rear
Steering mechanism : Direct servo
Shock damper : Oil-filled damper
Shock damper material : Aluminum
Tire type : Not included
Tire tread : N/A
Body material : Not included
Chassis material : Carbon fiber plate
Electronic Speed Control (ESC) : Not included
ESC model : N/A
LED Light buckets : No
LED lights : No
Motor : Not included
Bearings : Flourine-Coated Ball Bearings
Adjustable camber : Fixed
Adjustable toe angles : Front only
Adjustable ground clearance : Yes
Adjustable gear ratio : Yes
Adjustable wheelbase : Fixed
Adjustable track width : Fixed
Adjustable shock angle : Yes

Features

TRF102 Carbon Lower (2.5mm Thick) & Upper (2.0mm Thick) Decks
TRF102 Carbon Lower (2.5mm Thick) & Upper (2.0mm Thick) Decks
F104 Low-Friction Suspension Balls
Reinforced Carbon Reinforced Plastic Front Suspension Arms
TRF102 T-Bar Rear Suspension
Adjustable Metal Upright Set included
Integrated Diff Plate/Carbon Rear Shaft
TRF102 Aluminum Servo Stay
1.5mm & 1.8mm T-bars
Aluminum parts come in black.

Requires

2-channel radio gear
Polycarbonate paint
7.2 battery & charger
