Tamiya 58265 - 1/10 Toyota bB M-03L 豐田 田宮遙控模型M車(迷你車)套件 雙星孖星  [58265]

• Targeted towards consumers in their twenties, Toyota&39;s mysterious bB was released in February 2000, and falls into the small minivan class that is sweeping Japan.
• Tamiya undertakes the replication of this promising car as an electric powered RC assembly model kit on the all new M-03L Chassis.
• The M-03L is an ABS monocoque chassis with a separate polycarbonate gearbox. This chassis is finished in all black, differing from the gray colored M-03 chassis.
• It features an elongated wheelbase of 239mm, which makes it one of the longest FF chassis.
• The bB is equipped with four wheel double wishbone suspension and low friction dampers for smooth running performance.
• All new curved spoked wheels and 60D radial tires complete this quality chassis.
• The box-like exterior of the bB (which incidentally stands for black Box) has been accurately recreated in shock resistant polycarbonate.
• Various original stickers such as "side flames" are also included to give some extra style to the bB.

Specification:

• Overall length: 365mm
• Overall width: 167mm
• Overall height: 147mm
• Minimum clearance: 9.5mm
• Weight: 896g (not including RC system and battery)
• Wheel base: 239mm
• Tread: (front&rear): 138mm
• Chassis material: polycarbonate
• Chassis layout: monocoque frame
• Steering Tie Rod: divided in 2 segments
• Suspension: front and rear double wishbone
• Caster Angle (front/rear): 5°/0°
• Camber angle (front&rear): 0°
• Toe angle (front&rear): variable/0°
• Dampers (front&rear): friction dampers
• Drive train: FF
• Gear ratio: 5.80:1
• Diff. gear system: 3-bevel diff. (front only)
• Tire width (front&rear): 25mm
• Tire diameter (front&rear): 59mm
• Tread pattern (front&rear): radial
