Tamiya 42277 - 1/10 RC TRF201XM Chassis Kit 田宮遙控模型越野車套件 雙星孖星  [42277]

The TRF201XM chassis used by Tamiya Racing Factory pilot Lee Martin at the 2013 IFMAR 2WD Off-road World Championships is available for racing enthusiasts across the world to drive! The kit features theTRF201 converted into a mid-motor chassis, including modifications beyond those offered by the conversion kit seen in Item 42257 TRF201 XM Conversion Set.

Specification

• Scale : 1/10
• Construction type : assembly kit
• Terrain use : off-road
• Drive-train : 2WD
• Drive type : gearbox
• Drive line : universal
• Differential type : sealed oil-filled gear
• Suspension : fully independent double wishbone
• Steering mechanism : bell-crank
• Shock damper : oil-filled damper
• Shock damper material : aluminum
• Tire type : not included
• Tire tread : n/a
• Body material : Polycarbonate
• Chassis material : aluminum
• Electronic Speed Control (ESC) : not included
• ESC model : n/a
• LED Light buckets : no
• LED lights : no
• Motor : not included
• Bearings : shielded ball bearing
• Adjustable camber : yes
• Adjustable toe angles : front and rear
• Adjustable ground clearance : yes
• Adjustable gear ratio : yes
• Adjustable wheelbase : fixed
• Adjustable track width : fixed
• Adjustable shock angle : yes
• Special feature 1 : The aluminum chassis deck features new dimensions to seize the potential of the new gear case.
• Special feature 2 : The gear case allows for a new drive shaft attachment angle. The aluminum motor plate and suspension mount, plus the center post, have been redesigned to work optimally in the new setup.
• Special feature 3 : A new carbon rear damper stay facilitates more efficient upper arm attachment positions.
• Special feature 4 : The TRF201 chassis features 4-wheel double wishbone suspension and aeration oil dampers for smooth and effective damping.
• Special feature 5 : The kit is compatible with the included ball differential, and also gear differentials.
• Special feature 6 : Includes a Pro-Line Phantom body.
• Requires A : 2-channel radio gear & electronic speed control
• Requires B : 7.2 battery & charger
• Requires C : motor
• Requires D : tires
