Kyosho 30617 - 1/10 Optima 4WD Off-Road Racer Kit Vintage Series Buggy 京商越野車經典系列  [KY30617]

The Vintage Series ,Return of the Legend,the Optima 4WD Off-Road Racer 1/10th Scale Radio Control Electric Powered 4WD Racing Buggy.

Speed has form. The winning formula is …The first OPTIMA model was heralded as a technical masterpiece at its release in 1985 and from then, Kyosho has set the standard in R/C development. Memories of the OPTIMA are fresh even after 30 years and its stylish form and ruthlessly efficient performance still resonate amongst modern racing machines. Now the new OPTIMA is ready to continue the battle for racing dominance, embodying the latest in technological evolution but with the distinctive OPTIMA style. The narrow backbone shaped chassis provides the platform for optimal geometry with large steering angles and double wishbone suspension with long 35mm suspension stroke. Recreated in the image of the original design, the the 4WD chain system is housed inside a sealed compartment and the gears and gearbox at the center of the drive train are equipped with robust metal counter gear pinion and rear diff case. The drive train also features a slipper clutch and precision 48-pitch gear modules that reduce drive loss and fulfill the potential of modern power sources. Modern features include the choice of chain drive or belt drive as well as big bore shocks on front and rear that have been recreated in the original OPTIMA colors, plus hex screws. As a true racing partner, the OPTIMA is ready to race again with the latest advancements in driving performance.

The Optima is designed based on the original version released in the 80s. We have updated several areas but kept the parts compatible with the original chassis.

• The “OPTIMA” name signifies optimal performance. This famous off-road racer is equipped to win in any conditions.
• 4WD mechanics are condensed into a narrow open frame chassis 6061T6 aluminum bars (caunter sunk)
• Two drive system selections: chain drive or belt drive.
• Gearbox equipped with slipper clutch for transmission protection and effective traction control.
• Precision 48-pitch gear modules. Sintered alloy gears combined with high impact nylon gears and newly added slipper clutch. This durable design allows efficient power delivery and will cope with the current high power motors.
• Precision 48-pitch gear modules deliver reduced drive loss. Metal rear diff case and metal gears deliver excellent durability.
• Glass mixed nylon material used in rigid double wishbone system suspension.
• Strong impact-resistant resin bumper. Includes mini bumper suitable for racing and large bumper for sports driving.
• Includes special tool for shock absorbers. Can be used as a 5, 5.5 and a 7mm wrench.

New features:

• Chassis: All plates and the main chassis bars are now 6061T6 aluminum(counter sunk).
• Aluminum chassis bars are slightly thicker for more durability.
• Drive-train: Kit includes both chain and belt drive trains allowing use of more powerful motors.
• Diff gears now have ball bearings installed.
• Gears: Now in 48 pitch gears. Sintered alloy gears combined with high impact nylon gears and newly added slipper clutch will cope with the current power plants.
• Shocks: New 10mm diameter aluminum cylinder with SUS shaft allows improved damping.
• Tires / Wheels: Slightly modified tread designs and new softer compound for superior grip and handling. Rear tires include inner sponge. New 1 piece wheel design.
• 2 Types of bumpers included(Wide and Narrow)
• Aluminum motor guard.
• Updated geometry.
• Hardware: All Hex
• Updated servo fixture.
• Driver: Molded helmet design.
• Option Parts: We will release various option parts.
• Electronics compatibility: Compatible with the current standard servos, Receiver units, ESCs, motors and battery packs.
• Packaging: Similar to the original with blister pack showing some of the parts included. Some parts will be preassembled and parts will be bagged in steps following the instruction manual for easy assembly.

Kit Contents:

• Pre-assembled kit (gearbox and oil shocks are pre-assembled)
• Clear polycarbonate body
• Decals
• L-shape hex wrench
• Cross wrench
• Shock wrench
• Shock oil
• Grease
• Threadlock glue

Required for operation:

• 2-channel R/C system (servo x 1, ESC x 1)
• 540 Size Motor
• 7.2V NiMH battery or 7.4V Li-PO battery
• Charger for motor battery (For DC: Regulated 12V power supply)
• Tools for body painting
• Batteries for transmitter
• Tools (phillips head screw driver large, small. Needle Nose Pliers, Scissors, Sharp Hobby Knife)

Chassis Technical Data

• Length: 395mm
• Width: 240mm
• Height: 120mm
• Ground Clearance: 36mm
• Wheelbase: 260mm
• Tread (F/R): 204mm / 204mm
• Tire(F/R): 86f x 40mm / 86f x 40mm
• Gear Ratio: 9.24:1
• Weight: approx. 1,600g
• Motor: 540 class size
• Battery: Ni-MH / Li-PO ,Li-PO: Standard Size / short size
• R/C System: 2 channel, 1-servo, ESC
