Large, isolated solder posts for quicker, safer wire attachment.
Features Include:
Controllable frequency by load response One push switch for setting neutral Current limiter Heat protection / Slow down Low Voltage protection / For LiPo or LiFe Reverse terminal protection Alarm 3 colors LED Serial communication Aluminum upper case / middle case / heat sink (Option) Super core wire 14AWG Data logging Reverse function Setting Menu: PWM frequency (at Min. load) PWM frequency (at Max. load) PWM frequency at Brake Dead Band Low Batt. Protection Current Limiter Current Limiter (Time Limit) Current Limit timer Brake Max. Duty Reverse Max. Duty Neutral Brake Boost Brake timer Reverse mode shift level Lead Angle (Motor timing) Reverse Cancel Robot Mode Current Limiter disable
SPECIFICATIONS
Stock Number: FUTM0955 Forward / Reverse (Brake): 255 step Power Requirements: Nicd, NiMH battery 4-7 cells (4.8-8.4V) Motor limit: Over 2.5T (With optional heat sink & fan) Input voltage: NiCd / NiMH 4~7 cells (4.8V~8.4V) Forward PWM frequency: 500~30,000Hz/Initial Value: 3.0kHz~5.0kHz Reverse (Brake) frequency: 500~30,000Hz/ Initial Value: 1.0kHz Max current: 900A (Momentary load: 1300A) Size: 37.2 x 36.6 x 14mm Weight: 33.3g BEC: 6V / 2A Data logging: 1024sec (1 sec step) Serial communication: 9,600bps (8bit) FET: 30pcs (5pcs/pole) Setting: One-touch input by push button switch
